Rotor Aluminum Die Casting Machine

Large Image : Rotor Aluminum Die Casting Machine Get Best Price

Product Details:

Place of Origin:	Chinese rotor die casting machine
Brand Name:	Wind Automation
Model Number:	Rotor aluminum die casting machine

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	USD

Contact Now

Detailed Product Description

Rotor Aluminum Die Casting Machine Parameter:

Rotor OD: 40-80mm

Core length: 16-100mm
Max casting weight: 0.6kgs
Rotor core: without opening slot
Working pressure of upper cylinder: 40T
Working pressure of lower cylinder: 12T
Max working pressure of liquid aluminum: 22.6MPa
Oil tank capacity: 425L

Max aluminum filling capacity in our present standard machine:

Diameter 75mm x Height 60mm. It is about 500 grams

Running speed of pressing and shooting piston: slow shooting 190mm/s, fast shooting 600mm/s
Hydraulic system: 40L variable piston pump with 7.5KW motor
Working efficiency: 8s
Power: 380v/50Hz, 8.5KW
Weight: 2000kgs

Dimensions: 1800(L) x 1800(W) x 2350(H)mm
